Texturized fiberglass cloth is a high-performance industrial fabric woven from air-texturized fiberglass yarns, specifically designed for high-temperature, thermal insulation and fire protection scenarios. It is a non-asbestos, environmentally friendly material with excellent comprehensive properties, widely used in various industrial fields requiring heat resistance and flame retardancy.
Its core characteristics include outstanding high-temperature resistance, capable of withstanding continuous high temperatures of 500-1000℃ without deformation or damage; superior thermal insulation performance, with low thermal conductivity to effectively block heat transmission and reduce energy loss; excellent fireproof and flame-retardant effects, not burning, not melting, and effectively preventing the spread of fire. Additionally, it has good flexibility, tensile strength and wear resistance, easy to cut and install, and durable in harsh industrial environments.
In industrial applications, it is mainly used for high-temperature equipment insulation (such as boilers, furnaces, pipelines), thermal insulation of industrial kilns, fireproof wrapping of electrical components, fireproof separation in factories, thermal barrier layers of high-temperature pipelines, and auxiliary insulation in metallurgy, petrochemical, power, aerospace and other industries, providing reliable thermal protection and fire safety guarantees.
|
Style |
Weave |
weight |
Thickness |
Warp Yarn |
Weft Yarn |
Width |
Density |
Post-processing |
|
84215 |
Plain |
280 |
0.38 |
ET6-215 |
ET6-215 |
1000-2100 |
8×6 |
*Dyeing and weave lock, |
|
2025 |
Plain |
610 |
0.75 |
ET6-430 |
ET6-430 |
1000-2100 |
8×6 |
|
|
M24 |
Plain |
816 |
1 |
ET9-860 |
ET9-860 |
1000-2100 |
6×3.8 |
|
| M24S |
M24 with 316L or 304 Stainless Steel Wire |
|||||||
|
M30 |
Plain |
1020 |
1.4 |
ET9-860 |
ET9-1250 |
1000-2100 |
6×4 |
|
|
M30S |
M30 with 316L or 304 Stainless Steel Wire |
|||||||
|
M35 |
Plain |
1190 |
1.5 |
ET9-860 |
ET9-1800 |
1000-2100 |
6×3.8 |
|
|
M35S |
M35 with 316L or 304 Stainless Steel Wire |
|||||||
|
M44 |
Plain Panama |
1500 |
2 |
ET9-860 |
ET9-860 |
1000-2100 |
12×5 |
|
|
M52 |
Plain Panama |
1780 |
3 |
ET9-860 |
ET9-1290 |
1000-2100 |
6X2/2.5x2 |
|
|
M64 |
Plain Panama |
2300 |
3 |
ET9-1290 |
ET9-1400 |
1000-2100 |
12×5 |
|
