High Temperature Sewing Threads

PTFE Coated Fiberglass Sewing Thread

Code

Type

Thickness
(mm)

Strength
(N)

Length

(m/kg)

T12

ECBC150 2/2 9.5Z

0.28

77

6000

T18

ECBC150 2/3 9.5Z

0.38

95

4000

T24

ECBC150 2/4 9.5Z

0.48

116

3000

T40S3/6S

550D 1/3 +6ply wires

0.40

87

3800

T2

ECD75 1/2 7Z

0.25

75

6000

T3

ECD75 1/3 7Z

0.35

90

4000

T208P

ECDE75 1/3 7Z

0.30

70

4500

Spun Para Aramid Sewing Thread

Code

Composition
Material

Thickness
(mm)

Strength
(N)

Length

(m/kg)

T30/3

30/3 spun para aramid

0.26

65

15000

T20/3

20/3 spun para aramid

0.29

72

10000

T30/3G

30/3 spun para aramid with coating

0.26

75

13000

Spun Para Aramid Sewing Thread with SS Wire

Code

Composition
Material

Thickness
(mm)

Strength
(N)

Length

(m/kg)

T16S/3

spun para aramid + 3ply wires

0.30

65

8600

T30S/4/6S

spun para aramid + core 6ply wire s

0.38

70

4800

T30S/4/8S

spun para aramid + core 8ply wires

0.40

75

4400

T30S/4/10S

spun para aramid + core 10ply wires

0.42

80

4000

T30S/4/4/4S

spun para aramid + 4ply wires + core 4ply wires

0.40

90

4400

Para Aramid Sewing Thread with SS wire

Code

Composition
Material

Thickness
(mm)

Strength
(N)

Length

(m/kg)

T400D4S

400D para aramid + 4ply wires

0.16

95

9600

T600D6S

600D para aramid + 6ply wires

0.20

110

6600

T1000D3S

1000D para aramid + 3ply wires

0.24

135

6000

T1000D4S

1000D para aramid + 4ply wires

0.26

140

5700

T1000D6S

1000D para aramid + 6ply wires

0.28

150

5100

T1000D8S

1000D para aramid + 8ply wires

0.33

160

4600

T1000D10S

1000D para aramid + 10ply wires

0.35

165

4000

T400D3/6S

400D3 para aramid + 6ply wires

0.36

214

4600

T400D3/10S

400D3 para aramid + 10ply wires

0.38

226

3800

T1500D3/10S

1500D3 para aramid + 10ply wires

1.00

550

1500

T1000D6SP

1000D para aramid + 6ply + PTFE

0.28

150

4500

T200D4F/8S

200D4 para aramid + 8ply wires

0.30

145

4500

T200D3/1S

200D3 para aramid + 1ply wire with coating

0.20

135

9500

Silica Sewing Thread

Code

Type

Thickness
(mm)

Weight
(kg/roll)

Length

(m/roll)

TSY216P

Machine sewing

0.30

1.0

4500

TSY220P7

Machine sewing
Higher performance

0.30

1.0

4500

TSY570P

Hand sewing

0.46

0.5

900

Quartz Fiber Sewing Thread

Code

Thickness
(mm)

Strength
(N)

Weight
(kg/roll)

Length

(m/roll)

TQY220

0.20

100

0.14

630

TQY320

0.45

100

0.15

500

Stainless Steel Fiber Sewing Thread

Code

Composition
Material

Thickness
(mm)

Strength
(N)

Length

(m/kg)

T3041003

100x3-Z252T-PTFE 60%

0.20

100

3000
