| Style | 480S | 480S-1/5 | 640S | 660S-1/8 | 825S | M24S | M30S | M35S | Post-Processing and typical applications |
| Warp Yarn | EC9 68*2+Steel wire | EC9-68*3 & EC9 68*2+Steel wire |
EC9 68*2+Steel wire | EC9-68*3 & EC9 68*2+Steel wire |
EC9 68*3+Steel wire | ET9 860+Steel wire | ET9 500+Steel wire | ET9 860+Steel wire | PU coated for fire and smoke curtains; Silicone coated for thermal insulation blankets; vermiculite coated foer thermal insulation blankets. |
| Fill Yarn | EC9 68*2+Steel wire | EC9-68*3 & EC9 68*2+Steel wire |
EC9 68*2+Steel wire | EC9-68*3 & EC9 68*2+Steel wire |
EC9 68*3+Steel wire | ET9 860+Steel wire | ET9 500+Steel wire | ET9 1800+Steel wire | |
| Weave | Plain | 5H Satin | 8H Satin | 8H Satin | 8H Satin | Plain | Plain | Plain | |
| Thread Count Warp (Per inch) |
30±1 | 30±1 | 40.6±1 | 40±1 | 40.6±1 | 15±2 | 30.5±2 | 15±2 | |
| Thread Count Fill (Per inch) |
31±1 | 31±1 | 39±1 | 40±1 | 38.1±1 | 9.5±1 | 19.2±1 | 10±1 | |
| Basic Weight (g/m2) | 480 | 480 | 640 | 660 | 825 | 820 | 1020 | 1200 | |
| Thickness(mm) | 0.4 | 0.4 | 0.55 | 0.6 | 0.7 | 0.8 | 1.0 | 1.5 | |
| Tensile strength Warp (N/2.5cm) | / | ≥1800 | ≥2300 | ≥2400 | ≥2700 | / | / | / | |
| Tensile strength Fill (N/2.5cm) | / | ≥1500 | ≥2200 | ≥2200 | ≥2700 | / | / | / | |
| Working Temperature (ºC) | 600 | 600 | 600 | 600 | 600 | 600 | 600 | 600 |
